APEXX S1 workstation pc

APEXX S1 workstation pc

APEXX S1 workstation pc

Only 20” deep, the cost-effective RAXX T3L is ideal for extreme multitasking in feature film editing, VR deployment, and other production workflows requiring maximum CPU cores at a high frequency.

BASIC CONFIGURATION

  • 16-core AMD Ryzen™ Threadripper™ Pro 3.9GHz
  • 64GB DDR4-3200MHz ECC REG
  • NVIDIA® Quadro® P2200 5GB
  • 500GB M.2 NVMe 4.0 SSD
  • Microsoft® Windows™ 10

Chassis images are generic. Check the specs
tab for information specific to this model.

Specification

Chipset:AMD WRX80
Socket:Single (sWRX8)
CPU Cooling:Liquid-Cooled (closed loop)
Processor:AMD Threadripper Pro
Core Frequency (GHz):2.7 Base clock / 4.2 Boost clock
Cores/Threads:64/128
Multi-Threading:Yes
Max Configurable Memory:2TB DDR4-3200MHz ECC REG
DIMM Slots:8
PCIe Slots:

x16, x16(x8), x16, x16, x16, x16, x16

Supported GPU Configurations:

Up to 4 GPUs at x16

2.5" Drive(s):10 (Up to 8TB each)
3.5" Drive(s):N/A
Shipping Dimensions:

24” (60.96cm) W
15” (38.10cm) H
33” (83.82cm) D

Shipping Weight:60 lbs.
M.2 Drive(s):2 (Up to 2TB each)
U.2 Support:Yes
RAID Support: 0, 1, 5
OCuLink Support:No
Onboard Wi-Fi:N/A
Onboard Bluetooth:N/A
Power Supply:2000-watt x 2 (80 PLUS Titanium)
GPU Power Budget (W):1000
Product Dimensions:

17.3" (43.94cm) W
5.22" (13.25cm) H
24.0" (60.96cm) D

Front I/O:

2 x USB 3.2 Gen 2
Audio Out/Mic In

Rear I/O:

2 x 10GbE LAN (RJ-45)
2 x 1GbE LAN (RJ-45)
IPMI sideband support
1 x Optical S/PDIF out
7-Channel Audio
5 x USB 3.2 Gen 2 Type A
1 x USB 3.2 Gen 2 Type C
1 x VGA BMC Port
1 x Serial Port

Optical Drive Option:DVD±RW or Blu-Ray RW (5.25")
Rackmount Option:Yes
Notes:

Highest available CPU core count and associated clock speeds shown. Other processors with different core counts and frequencies may be available.

GPU power budgets are conservative estimates.

Shipping weights vary by configuration.

Support

Most BOXX workstations include a standard three-year limited warranty and legendary BOXX Technical Support. Providing unparalleled hardware and software expertise, our support team is located at company headquarters in Austin, Texas and equipped with the tools and resources necessary to support you and your workflow.
