Apexx S3

APEXX A3 features an AMD’s Ryzen™ 3000 Series processor, and is a versatile platform for demanding 3D content creation workflows. In addition to the blazing fast CPU, the A3 offers ample memory, up to two professional GPUs, and plenty of hard drives.

Starting Price $3,178.00

BASIC CONFIGURATION

  • 16-core AMD Ryzen 3000 Series processor
  • 16GB DDR4-2666MHz
  • NVIDIA Quadro P620 2GB
  • 250GB M.2 PCIe SSD
  • Microsoft Windows 10 Pro

Specification*

Chipset:AMD X570
Socket:Single (AM4)
CPU Cooling:Liquid-Cooled (closed loop)
Processor:AMD Ryzen 3rd Gen
Core Frequency (GHz):3.5 Base clock / 4.7 Boost clock
Cores/Threads:16/32
Multi-Threading:Yes
Max Configurable Memory:128GB DDR4-2666MHz
DIMM Slots:4
Physical PCIe Slots:

5 x PCIe 4.0 (1 x16, 1 x8, 1 x4, 2 x1)

PCIe Lanes per GPU:

x16
x16/x8

2.5" Drives:4 (Up to 4TB each)
3.5" Drives:2 (Up to 14TB each)
M.2 Drives:3 (Up to 2TB each)
RAID Support: 0, 1, 10
Max 2.5" / 3.5" Configurations: 2 x 3.5" | or | 1 x 3.5" + 2 x 2.5" | or | 4 x 2.5"
Onboard Wi-Fi:802.11ax
Onboard Bluetooth:v5.0
Power Supply:750-watt (80 PLUS Gold)
GPU Power Budget (W):450
Chassis Dimensions:

6.84" (17.37cm) W
15.28" (38.81cm) H
17.80" (45.21cm) D

Front I/O:

4 x USB 3.1
Audio Out/Mic In

Rear I/O:

2 x Antenna
1 x HDMI 2.2
1 x USB 3.2 Gen2 Type-C
1 x USB 3.2 Gen2/Gen1 Type-A
1 x USB 3.2 Gen2 Type-A
3 x USB 3.2 Gen 1
4 x USB 2.0/1.1
1 x Gigabit LAN
7.1-Channel HD Audio

Optical Drive:No

Support

Most BOXX workstations include a standard three-year limited warranty and legendary BOXX Technical Support. Providing unparalleled hardware and software expertise, our support team is located at company headquarters in Austin, Texas and equipped with the tools and resources necessary to support you and your workflow.

Media Reviews

engineering.com - Aug 27, 2018
What’s in the BOXX? A Review of the APEXX S3 Workstation
"The BOXX APEXX S3 is a powerhouse workstation that’s designed to hold up to demanding CAD applications...easily running applications that bring lesser computers to a grinding halt."

Customer Reviews

It is peace of mind—knowing that when I have a tight deadline, I don’t have to worry about my machine working. That’s a big deal. Or I know if I run into a problem, I can call you guys. I have full confidence in BOXX and that’s a huge deal because you don’t needed added stress on top of everything else and deadlines are always shifting.
Duane Addy, 27-year architect w/over $750 million in projects
